Small cubic acme screw jack

Small acme Screw jack has compact structure and is a basis jackup part, accomplish the functions such as lifting, drop,
push and inverting through  worm gear drives screw.

  • Item No.:

  • Product origin:

  • Color:

  • Shipping port:

  • Lead Time:

    20 days after payment received
follow us :
  • Product Details

  • Photo

Brief introduction:

Small acme Screw jack/lift is a basis jack-up part, accomplish the functions such as lifting, drop, push and inverting through worm gear drives screw.

The worm shaft is supported on anti-friction tapered roller bearings with external seals that prevent lubrication loss.Its load capacity can be from 5kN to 100kN.

small acme screw jack with traveling nut

Main parameters:

Maximal load:50kN

Screw Thread size: Tr40×7

Worm ratio:1:4(high speed H) / 1:16(low speed L)

Amount of lift per revolution for ratio H: 1mm

Amount of lift per revolution for ratio L: 0.25mm

Permissible input maximal power: 0.57kw

ACME Jack's Features:

It is suitable for low speed and low frequency.
Main components:Precision trapezoid screw pair and high precision worm-gear pair.
Compact design,easy operation,convenient maintenance.
2.Low speed and low frequency
Be suitable for heavy load,low speed,low service frequency.
Trapezoidal screw has self-lock function,it can hold up load without braking device when screw stops traveling.
4. Widely applied in industries such as machinery, metellurgy, construction and hydraulic equipment.
5. Top End: top plate, clevis end, threaded end, plain end

Small acme screw jack is applied in spray infeed conveyor lift system, theatre stage lifting platform, solar tracker, satellite dish antenna azimuth, raising sluice gate, screw scissor lift table, synchronized lifting system, food processing oven lifts system, feeder leveler, roller adjustment, tunnel ventilation damper adjustment, postform roller elevation, car lifting trolley, extrusion machine etc.

cubic acme jack screwcompact screw jack lift
