Rotating Ball Precision Screw Jack 10 ton
  • Product Origin:

    Dezhou
  • Shipping Port:

    Qingdao/Tianjin/Shanghai
  • Color:

    Customized
  • Lead Time:

    20-30 days after payment received
Ball screw jack 's lifetime is about 3 times of acme screw jack and has the advantages of high efficiency and high speed.
Inquiry now
  • Product Details
  • Photo


Brief Instruction

Rotating Ball Screw Jacks use a ball screw and nut made from hardened alloy steel with bearing balls carrying the load between nut & screw. They can be employed for lifting, pulling, moving, aligning any kind of load with a perfect synchronism, which is difficult to obtain by means of other handling devices.The ball worm screw lifts are suitable for high services as well as for a very rapid, quick and precise positioning.


Main Parameters:

Maximal load:50kN
Outer diameter of screw: 50mm
Small diameter of screw: 39.1mm
Pitch of screw: 12mm
Worm ratio:1:8(high speed H) / 1:24(low speed L)
Amount of lift per revolution for ratio H: 1.5mm
Amount of lift per revolution for ratio L: 0.5mm
Permissible output maximal power: 3.6kw(high speed)   1.9kw(low speed)


Main Features:1.High efficiency   2.high speed  3.Lifetime longer


Photos:








Rotating Ball screw jack of small size:

 small ball screw jack with traveling nut


rotating ball worm screw jack

Ball screw jack parts:
