• Worm Gear Screw Lift Running-In
    Worm Gear Screw Lift Running-In
    We all know that there is a running-in period for the use of machinery and equipment. During the running-in period, as long as we are properly tuned, we can reduce unnecessary troubles in future use by finding problems in time.  What we should pay attention to during the worm gear screw lift use? Worm screw lifts are generally self-locking static state.( Note: self-lock is a function of acme ...
    Nov 08 , 2015 view more
  • Rotating ball screw lifts JWB025 of worm ratio 6:1
    Rotating ball screw lifts JWB025 of worm ratio 6:1
    JWB025 Ball Worm Gear Screw Lift Picture JWB025 Ball Worm Gear Screw Jack Descriptions 1. Maximal Load: 24.5kN 2. Stroke: 85mm 3. Ball screw outer diameter : 25mm Ball screw inner diameter:21.4mm 4. Screw pitch: 8mm 5. Worm Ratio:6:1 6. Lift screw travel (mm), per turn of worm shaft (H: high ratio): 1.33mm 7. Efficiency %: 62 8. Permissible input torque (N.m) : 49 9. Max. Permissible input power (...
    Dec 18 , 2017 view more
  • Features of Worm Ball Screw Lift
    Features of Worm Ball Screw Lift
    Ball screw is the most commonly used machine tool and precision mechanical transmission components, its main function is to convert rotary motion into linear motion, or torque into axial force, while both high precision, reversibility and high efficiency characteristics. Ball screw pair work principle. Right amount of balls are put in between the screw and nut , making the sliding friction between...
    Dec 18 , 2017 view more
  • How do rotating screw jack and translating screw jack work?
    How do rotating screw jack and translating screw jack work?
    According to movement type, the worm gear screw jack can be classified to translating screw jack and rotating screw jack. Then how do these two types of screw jacks work?Let’s see the followings. ---Translating screw jack The rotation of the worm shaft causes the worm gear to rotate. For translating screw jacks the worm gear is threaded to accommodate the lead screw thread. As the worm gear turns,...
    Dec 05 , 2017 view more
  • Difference between screw pitch and lead
    Difference between screw pitch and lead
    The screw can be of single start,double starts or multiple starts.The multiple-start worm gear screw jack is widely used in application which requires higher speed. Then how about the difference between the screw pitch and lead in multiple-start screw?  Let’s see the following information. Pitch Pitch is the distance between screw grooves and is commonly used with inch sized products and spec...
    Nov 28 , 2017 view more
  • Linear Actuator ---Worm screw jacks' upgrading product
    Linear Actuator ---Worm screw jacks' upgrading product
    Linear actuator is a kind of product upgraded from worm gear screw jack. It has special metal shell which can move along with the screw. It is more durable and easy to be maintained and has higher precision. This product can be divided into ordinary teeth screw electric push rod (working system is 30%) and ball screw electric push rod (working system 100%) Electric push rod drive can be optional D...
    Nov 08 , 2017 view more
